Extra-long precision ground tables provide a stable work surface.
Parallelogram design provides smooth accurate cuts.
Cast iron frame offers stable table support
Fully enclosed cabinet with 4” port for superior dust management.
Oliver HCX Helical cutterhead with premium carbide inserts.
4-sided cutting inserts are indexed and easy to replace.
Lever controlled infeed and outfeed table adjustment allows quick set-up.
Long precision ground fence tilts up to 135° with positive stops at 45° and 90°.
Easy to read depth of cut gauge.
Large lockable paddle switch for added safety.
Powerful TEFC 1HP single-phase motor.
Ploy V-belt drive efficiently delivers power to the cutter head.
CSA Listed.

Model Number 4225
Stock Number 4225.201 (1 HP, 1Ph, Helical)
Infeed Table Travel 1/2″
Cutterhead Speed 5,500 (RPM)
Number of Knives (helical) 28 Inserts
Maximum Depth of Cut 1/8″
Rabbeting Capacity 1/2″
Dust Port Diameter 4″
Table Dimensions 60-3/4” L x 5-3/4” W
Table Height 31-1/2″
Fence Dimensions 29”L x 3-3/4”H
Fence Tilts 45°, 90°, 135°
Positive Stops 45° and 90°
Motor 1Ph 1HP, 115V/230V, Prewired 115V (1Ph, 13/6.5 Amp)
Net Weight 240 lbs.
Gross Weight 375 lbs.
